The HL635VL suits medium-volume operations processing 80-150 tonnes per hour, such as municipal road construction projects, agricultural material handling on farms, or small aggregate operations supplying local building projects. Its 1.7 m³ heaped bucket capacity and 96 kN breakout force handle compacted soil, gravel, and agricultural materials without compromising cycle times.
The power shift transmission features four forward speeds and two reverse speeds that adapt to varying operational requirements. First gear provides 8.5 km/h for precise loading operations. Second gear delivers 13.0 km/h for short-distance material transport. Third gear achieves 24.0 km/h for medium-range hauling. Fourth gear reaches 37.0 km/h for long-distance travel between work areas.
Front end loaders work effectively across diverse terrains with 350 mm ground clearance, 40-degree steering angle, and 5,710 mm turning radius. The extended 2,830 mm wheelbase provides enhanced stability during loading operations whilst the 11-degree rear axle oscillation maintains traction on uneven ground common in agricultural and construction environments.
Consider the HL635VL if your operation requires manoeuvrability in confined spaces combined with sufficient capacity for general construction and agricultural tasks. Operations consistently processing over 200 tonnes per hour may require higher capacity models.
Front end loaders are versatile earthmoving machines that move, load, and transport materials efficiently in construction, agriculture, and light quarrying operations. The Hyundai HL635VL delivers 92 kW of gross power through its Weichai WP6G125E22 Tier 2 engine, moving up to 1.7 m³ of material per cycle in medium-duty construction and agricultural applications. We supply the HL635VL to operational sites with full technical support and genuine parts available from our network of branches.
This 10,400 kg front end loader handles continuous operation in demanding municipal projects and agricultural sites where manoeuvrability and reliability directly impact productivity.
The Weichai WP6G125E22 engine features six cylinders with 105 mm bore and 130 mm stroke, displacing 6.7 litres. The HL635VL Front end loaders consume fuel from a 150-litre tank under typical load conditions. The 10,400 kg operating weight distributes across 17.5-25 12PR L3 tires as standard, with optional tube tires available for desert conditions.
The hydraulic system operates at 17 MPa system pressure through a 100 mL/r gear pump. Complete bucket cycles execute in 9.9 seconds: 5.3 seconds lifting, 1.0 second dumping, and 3.6 seconds lowering. This rapid cycle time maintains productivity in continuous loading operations.
Routine servicing includes 150-litre fuel tank, 130-litre hydraulic oil tank, 14-litre engine oil capacity, 42-litre transmission oil, and 18 litres each for front and rear axles. The optional engine coolant heater and fuel filler pump support operations in colder Highveld regions and remote agricultural sites.
| Specification |
| Engine |
| Gross Power |
| Operating Weight |
| Bucket Capacity (Heaped) |
| Breakout Force |
| Rated Load |
| Fuel Tank Capacity |
| Wheelbase |
| Standard Tires |
| Maximum Travel Speed (4th) |
| HL635VL |
| Weichai WP6G125E22, Tier 2 |
| 92 kW @ 2,200 rpm |
| 10,400 kg |
| 1.7 m³ |
| 96 kN |
| 3,000 kg |
| 150 litres |
| 2,830 mm |
| 17.5-25 12PR L3 |
| 37.0 km/h |
